E1W Cable Gland

Rupam E1W type brass indoor and outdoor cable gland is used with single wire armour (SWA) cable providing a seal on the cable inner sheath and the cable outer sheath. A detachable armour cone and clamping ring arrangement allows the cable to be easily disconnected from the equipment, for maintenance etc. This feature also facilities remote make off procedures when the termination is to be conducted in areas of restricted access. Separate tightening actions for the inner displacement seal and the armour termination affords maximum control cover the pressure applied do the cable inner bedding. This cable glands is designed and tested as per BS 6121: PART1:1989. It meets the requirement of EN 50262: 1999 and IEC 62444.
