E1X Cable Gland

Rupam E1X type brass indoor and outdoor cable gland is used with all types of wire braid armour, strip armour, pliable wire armour & steel tape armour (STA) cable providing a seal on the cable inner bedding and cable outer sheath. The cable gland provides mechanical cable retention and electrical continuity via armour termination. A detachable armour cone clamping ring arrangement allows the cable to be easily disconnected from the equipment, for maintenance etc. This feature also facilities remote make off procedures when the termination is to be conducted in areas of restricted access. Separate tightening actions for the inner displacement seal and the armour termination afford maximum control over the pressure applied to the cable inner bedding. This cable glands is designed as per BS 6121:PART 1:1989 and IEC 62444.
